Details
Thanks to the features and attention to detail built-in, and your desire to ride the unrideable, the Bigfoot VLT 1 is the electric fat bike that you'll forget is an electric fat bike until you realize just how far it's taken you.
The Manitou Mastodon Pro suspension fork offers 100mm of cold-weather-compatible travel while matching the frame's generous clearance for the 4.8” tubeless compatible tires and rims.
The best-in-class Shimano STEPS E8000 drive unit will extend the ride and give you the push you need to get through the tough stuff. The protected seat tube charging port allows easy access and quick charging, which we've cold-weather tested to ensure you can ride year-round with confidence.
- Aluminum fat bike frame with in-tube battery and room for up to 4.8" tires
- Shimano STEPS E8000 motor w/630Wh intube battery
- Manitou Mastadon Pro 100mm fat fork w/Dorado air spring
- SRAM NX drivetrain
- Sun Mulefut 80mm tubeless-compatible rims
- Terrene Cake Eater, 26 x 4.6", studdable tires
Specs
Motor | Shimano STEPS E-8000 |
---|---|
Battery | In-Tube 630Wh |
Frame | Bigfoot Fat Bike aluminum |
Fork | Manitou Mastodon Pro w/Dorado Air, 100mm Travel |
Headset | Acros Block Lock, sealed bearing |
Axles |
Front: 15 x 150mm Rear: 12 x 197mm |
Rims/Wheels | Sun Mulefut 80SL, 80mm wide, 26" |
Hubs | KT alloy, sealed bearing |
Spokes | Shadar Stainless, 14g, black |
Tires | Terrene Cake Eater, 26 x 4.6", Studdable |
Crankset | Samox alloy for E8000, 170mm, Eagle |
Chainrings | 32T, Samox 104 BCD for Shimano spline |
Chain | SRAM NX Eagle |
Rear Derailleur | SRAM NX Eagle |
Cassette/Rear Cogs | SRAM NX Eagle, PG-1230, 11-50T |
Shifters | SRAM SX Eagle 12 speed , Single Click E-MTB |
Handlebars | Norco 6061, 800mm, 20 mm rise, 35mm bore |
Tape/Grips | SDG Slater Lock On |
Stem | Norco Alloy, 50mm, 35mm bore |
Brakes | SRAM Guide T Hydraulic, 200mm front / 180mm rear rotors |
Pedals | VP Nylon Flat |
Saddle | WTB Volt 250 Sport |
Seatpost | TranzX Stealth Dropper, 100mm (S) / 125mm (M) / 130mm (L) Travel, 31.6mm, 1x Lever |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Charcoal / Small | 058817432958 | 0240010714 | |
Charcoal / Medium | 058817432965 | 0240010715 | 210000002244 |
Charcoal / Large | 058817432972 | 0240010716 | 210000002243 |
Charcoal / X-Large | 058817432989 | 0240010717 | 210000002245 |
