Yamaha Cross Core

Yamaha Cross Core
  • Color: Slate Gray
  • Color: Slate Gray
  • Color: White Opal/Blue
  • Color: White Opal/Blue
Please select options


Your daily trek isn’t like others. You’re surrounded by hills and you demand more than just a regular fitness bike. You want the efficiency of a road bike, ergonomic comfort of a flat handlebar, and power assist technology that allows you to charge the day. Grab your Cross Core and live Generation Go!

The Cross Core is designed around Yamaha’s outstanding PWSeries SE drive unit. Integrated with the bottom bracket, the drive unit provides a low center of gravity for exceptional handling. Yamaha’s unique side docking battery mount allows for a frame design with a lower stand-over height. While providing the smooth power assist expected by many e-bike users, Yamaha’s systems are equipped with powerful support and a natural, organic pedal-assist feel even in the high-speed setting. The 500 Watt-hour Lithium-ion battery pack provides reliable and long-lasting energy to power your rides, and when it’s time to replenish you can quickly charge the battery pack on or off the bike with the high-speed charger. Exclusive to Yamaha Power Assist Bicycles is a speed sensor engineered into the rear hub. Clean, protected, and out of sight, this sensor recognizes the slightest change in bicycle speed and helps adjust motor input to deliver a smooth and natural power assist feel for the ultimate ride experience. And for those riders who love ride information, the LCD multi-function display comes loaded with a full suite of functions, including speedometer, average speed, maximum speed, odometer, battery range, cadence, and stopwatch.

The Cross Core is equipped with high-quality components and accessories to ensure every ride is comfortable and hassle-free. A Shimano Sora drivetrain with a double chainring offers quick shifting and an optimum gear range. The Shimano Sora mechanical disc brakes with 160mm center lock rotors provide strong, dependable braking in all conditions. Cross Core is equipped with a powerful LED headlight to help guide the way, with an on/off button built into the multi-function display for easy access while riding. Additionally, the frame has built-in bosses ready to accept fenders and fenders, including Yamaha’s rear rack with integrated LED taillight (sold separately). For riders seeking a superior experience of e-bike technology, reliability, and performance, the Yamaha Cross Core delivers.

WARNING: This product can expose you to chemicals known to the state of California to cause cancer and birth defects or other reproductive harm. For more information, go to


Drive System PWSeries SE w/ ECO+, ECO, STANDARD, HIGH modes
Battery Type/Weight Side exit Yamaha 500Wh 36V Lithium-Ion
Recharge Time 4-hour
Max. Assisted Speed 20mph
Frame Yamaha hydroformed and butted aluminum, internal cable routing, fender and rack compatible
Fork Aerodynamic alloy, fender compatible, internal cable routing
Axles Front: 12 x 100mm
Rear: 12 x 142mm
Rims/Wheels 700c, double wall, eyelet spoke holes, width 24.5mm (outer) 19mm (inner)
Tires CST Sensamo Sumo, level-5 Flat Protection, reflective sidewall, 700 x 35c
Crankset Square taper, 165mm (53cm). 170mm (55cm and 58cm)
Chainrings 50/34T E-Ring 110 BCD
Bottom Bracket Square taper
Chain KMC X9e
Front Derailleur Shimano Sora (2 x 9) Braze-on
Rear Derailleur Shimano Sora RD-3000 GS 9-speed
Cassette/Rear Cogs Shimano 9-speed. 11/30T
Shifters Shimano 9-speed Sora trigger shifter, w/ gear selection window
Handlebars Alloy flat bar, 31.8mm diameter, 640mm width
Tape/Grips Ergonomic locking, two-tone
Stem 4-bolt faceplate, 31.8mm diameter
Brakes Shimano Sora BL-R3000 Mechanical Disc 160mm SM-RT68 Centerlock Rotor
Saddle Yamaha Road Plus Cro-Mo Rail
Seatpost Alloy 30.9 x 260mm (S), 315mm (M), 350mm (L) with 2-bolt adjustable tilt saddle rail clamp
Accessories & Extras Yamaha battery keys, battery charger, LED Headlamp, bell

* Subject to change without notice.


Yamaha Bicycles CrossCore

Yamaha Bicycles CrossCore Walkaround

Part Numbers

Option MPN Store SKU
Slate Gray / Small CCORESSLA
Slate Gray / Medium CCOREMSLA
Slate Gray / Large CCORELSLA
White Opal/Blue / Small CCORESOPA
White Opal/Blue / Medium CCOREMOPA
White Opal/Blue / Large CCORELOPA 210000001113
